Monroe 0'' RearShock Absorber for 1983-1991 GMC S15 Jimmy 4WD

911021 Monroe Shock Absorber


Extended length, in. :24 Inch
Collapsed length, in. :14-1/2 Inch
Upper mount: Cross Pin
Lower Mount: Eyelet
Shock Absorber; Reflex ®; OE Replacement; Nitrogen Gas Charged; Premium Limited Lifetime Warranty; Single
Attributes Type: Nitrogen Gas Charged With Coil Spring: No Internal Design: Monotube Adjustable Valving: No Extended Length (IN): 24 Inch Compressed Length (IN): 14-1/2 Inch Upper Mounting Style: Cross Pin Lower Mounting Style: Eyelet Body Color: Silver Quantity: Single Universality: Semi-Universal Rod Diameter (IN): 5/8 Inch Valving Type: Application Specific Valving Rod Material: Steel Body Material: Steel With Reservoir: No Includes Dust Shield: Yes Includes Hardware: Yes Includes Boot: No Estimated Install Time (Hours): 0.5 The Monroe Reflex® truck shock absorber with the patented ASD Technology combines specially tuned valving with a Fluon banded piston. The ASD valve has the ability to sense acceleration to improve the handling, safety, and overall ride characteristics of sport-utility vehicles, mini-vans and light trucks. The ASD base valve will sense a bump in the road and automatically adjust the shock to absorb the impact, leaving the shock with greater control when it is needed. The features of the Monroe® Reflex® truck shock absorber make it the superior shock for improved handling, safety, and comfort in all road conditions. Features & Benefits Innovative Valving Provides Greater Control For Handling, While Improving Ride Comfort All Weather Fluid Contains Special Modifiers To Reduce Friction And Ensure Smooth Rod Reaction The Fluon Band Provides Consistent Sealing Between The Piston And Pressure Tube Which Delivers Better Control And Increased Durability Full Displaced Valving: Tuned Specifically For Each Application And Automatically Adjusts To Road Extremes To Provide Consistency And Ride Nitrogen Gas Charged For Improved Ride And Handling, Helps Maintain Tire To Road Contact By Reducing Aeration Heavy-Duty Nitrocarburized Rod For Long Service Life Self-Lubricating' Fluid Seal Designed To Retain Gas Without Excessive Wear Or Friction Limited Lifetime Warranty

https://vehiclepartimages.com/PMDT/MON/TechnicalBulletins/TITAN SAF 5004 NA 200.pdf
[Type: Nitrogen Gas Charged, With Coil Spring: No, Internal Design: Monotube, Adjustable Valving: No, Extended Length (IN): 24 Inch, Compressed Length (IN): 14-1/2 Inch, Upper Mounting Style: Cross Pin, Lower Mounting Style: Eyelet, Body Color: Silver, Quantity: Single, Universality: Semi-Universal, Rod Diameter (IN): 5/8 Inch, Valving Type: Application Specific Valving, Rod Material: Steel, Body Material: Steel, With Reservoir: No, Includes Dust Shield: Yes, Includes Hardware: Yes, Includes Boot: No, Estimated Install Time (Hours): 0.5]
