ReadyLift 0'' Lift Kit for 2014-2016 GMC Sierra 1500 4WD

69-3416 ReadyLift Lift Kit Suspension

[Full Front and Rear]
Lift Kit Suspension; SST ® Series; 4 Inch Front Lift; 1-3/4 Inch Rear Lift; Without Shock Absorbers In Kit - Shock Change Not Necessary; Black Components; With Front Strut Extensions/ Rear Shock Absorber Extension Brackets/ Front Tubular Control arms/ Skid Plate/ Differential Drop Brackets/ Lift Blocks/ U Bolts And Hardware
Attributes Front Lift Amount (IN): 4 Inch Rear Lift Amount (IN): 1-3/4 Inch Front Lift Type: Strut Assembly Spacer Rear Lift Type: Leaf Spring Block Maximum Tire Size: 33 x 11.50 Shock Type: Without Shocks Wheel Backspacing (IN): 5.25 Minimum Wheel Diameter: OEM Wheel Offset (MM): OEM Shocks: Without Shock Absorbers In Kit - Shock Change Not Necessary Color: Black Components The Ready LIFT 69-3416 4 Inch SST Lift Kit combines many of the great features of our time-tested and very popular 4 Inch SST Lift Kit for the 2007 to 2013 trucks with new innovative features. Some of the features implemented into this system include a completely different differential drop mounting system which now utilizes machined billet circular spacers which allows for just the right amount of differential drop without interfering with the new rear-mounted electric steering rack. Additionally, a skid plate accompanies differential drop system. Factory changes to the spindle or upright allow us to now include the super strong heavy-duty ball joints we developed for the GM 2500 HD trucks but designed exclusively for the cast steel suspension on 2014 to 2018 GM 1500 trucks. These ball joints are vastly superior and are already installed into the tubular steel Upper Control Arms provided in the 69-3416 kit. This kit also includes newly designed UCA inner bushings and new washer backing spacer sleeves which greatly prolong the life of the bushings. Features & Benefits Solid Mount And Even Load Distribution Will Not Deform Or Change Shape No Cutting Of OEM Parts Or Welding Retain Factory Ride Quality Limited 1 Year Warranty

https://vehiclepartimages.com/PMDT/RDL/InstallationInstructions/69-3414_Instructions.pdf
[Front Lift Amount (IN): 4 Inch, Rear Lift Amount (IN): 1-3/4 Inch, Front Lift Type: Strut Assembly Spacer, Rear Lift Type: Leaf Spring Block, Maximum Tire Size: 33 x 11.50, Shock Type: Without Shocks, Wheel Backspacing (IN): 5.25, Minimum Wheel Diameter: OEM, Wheel Offset (MM): OEM, Shocks: Without Shock Absorbers In Kit - Shock Change Not Necessary, Color: Black Components]
